SPECIFICATIONS

FEEDING UNIT

1. Precise and smooth operation

2. Equipped with vacuum assist belt feeding system. The high friction belts ensure accurate feeding through the front mounted feed gates.

3. Adjustable paperboard press wheel. Suitable for B, C, BC flute 3ply and 5 ply paperboard.

4. The feeding unit linked with folding unit, speed is adjustable with variable speed motor.

5. The position of back stop sheet holder is adjustable.

FOLDING AND GLUING UNIT

1.      With a Unique model of folder gluer, we offer a top folding method while maintaining the square folded boxes running at variable speeds.

2.      Up folding with extended folding length to eliminate fish tailing.

3.      Separate operator control station.

4.      The movement of FOLDING ARMS is motorized and can be adjusted according to the size of box to allow a gradual unforced fold.

5.      Adapted high friction conveyer belt on upper and lower folding belts. Press down style through belts.

6.      The upper and lower belts work synchronously for correct output

7.      Glue application on flap by easy to operate wheel applicator.

SQUARIING/ COUNTING/EJECTING UNIT

1.      Top/ Bottom loading squaring hopper ensure accurate bundle count.

2.      The box is SQUARED upon coming out from the folding belts and then counted and ejected in the forms of bundles of required quantity.

3.      Available in 1 stage or 2 stage designs.

4.      Hold Down wheel for bundle compression

5.      Counting and feeding out system adopted through high friction belts.

SPECIFICATION TABLE

* Specifications and Design subject to change and improvement without prior notice
